digital phosphor oscilloscope

Tektronix TDS3034C Digital Phosphor Oscilloscope

November 15, 2011 By Test and Measurement Editor Leave a Comment

Tektronix-TDS3034C-DPO

Tektronix (www.tek.com) has introduced another member of its TDS3000C family that features four input channel, a maximum sampling rate of 2.5 GS/s and a record length of 10 k. This 300 MHz oscilloscope reduces learning curve as it features simple navigation and dedicated front-panel controls, effectively providing users more time on the task at hand. […]

Filed Under: Digital Oscilloscope, digital phosphor oscilloscope, Oscilloscopes Tagged With: digital phosphor oscilloscope, Tektronix

Tektronix TDS3052C Digital Phosphor Oscilloscope

July 21, 2011 By Test and Measurement Editor Leave a Comment

Tektronix (www.tek.com) has unveiled TDS3052C, a dual channel member of the TDS3000C Series oscilloscope that offers 500 MHz bandwidth, 5.0 GS/s sample rate and a record length of 10 k. By combining real-time intensity grading and 3,600 wfms/s continuous waveform capture rate, the TDS3052C enables users to clearly view the problem and solve it. Continuous […]

Filed Under: Digital Oscilloscope, digital phosphor oscilloscope, Oscilloscopes Tagged With: digital phosphor oscilloscope, Tektronix

Tektronix unveils compact TDS3054C digital phosphor oscilloscope

June 29, 2011 By Test and Measurement Editor Leave a Comment

Tektronix (www.tek.com) has released a 500 Mhz oscilloscope from its TDS3000C Series that offers the power of a DPO in a compact design that is just 5.9 inches (149 mm) deep and weighs only seven lb (3.2 kg) — the TDS3054C. This four channel oscilloscope also delivers a maximum real-time sampling rate of five GS/s […]

Filed Under: Digital Oscilloscope, digital phosphor oscilloscope, Oscilloscopes Tagged With: digital phosphor oscilloscope, oscilloscopes, Tektronix

Tektronix DPO7054C Digital Phosphor Oscilloscope

June 23, 2011 By Test and Measurement Editor Leave a Comment

Tektronix (www.tek.com) has introduced a 500 MHz oscilloscope from the DPO7000C Digital Phosphor Oscilloscope family — the DPO7054C. This four channel oscilloscope delivers a record length of up to 12.5 M points and a maximum real-time sampling rate of 20 GS/s on a single channel and five GS/s on all four channels. The oscilloscope offers […]

Filed Under: Digital Oscilloscope, digital phosphor oscilloscope, Oscilloscopes Tagged With: digital phosphor oscilloscope, oscilloscopes, Tektronix

DPO offers new dimension to oscilloscope architecture

May 23, 2011 By Test and Measurement Editor Leave a Comment

The digital phosphor oscilloscope (DPO) provides oscilloscope architecture a whole new approach. This architecture allows a DPO to deliver innovative display and acquisition capabilities to accurately reconstruct signals. Unlike a digital storage oscilloscope (DSO), which employs a serial-processing architecture to capture, analyze and display signals, a DPO uses a parallel-processing architecture to capture, display and […]

Filed Under: digital phosphor oscilloscope, Oscilloscope Descriptions Tagged With: digital phosphor oscilloscope, oscilloscopes

Tektronix MSO/DPO2000 Series debugs complex signals quickly

March 29, 2011 By Test and Measurement Editor Leave a Comment

Tektronix-MSODPO2000-Oscilloscope-Series

Tektronix (www.tek.com) has released a feature-rich tool that delivers the performance needed to visualize signals and speed debug of complex signals — the MSO/DPO2000 Series digital phosphor oscilloscope. This 20 channel oscilloscope features a bandwidth of 200 MHz and a real-time sampling rate of a maximum of 1 GS/s. All of its channels deliver a […]

Filed Under: Digital Oscilloscope, Oscilloscopes Tagged With: digital oscilloscope, digital phosphor oscilloscope, oscilloscope, oscilloscopes, Tektronix

Tektronix unveils DPO7000 Digital Phosphor Oscilloscope Series

February 4, 2011 By Test and Measurement Editor Leave a Comment

Tektronix-DPO7000-Digital-Phosphor-Oscilloscope-Series

Tektronix (www.tek.com) has released its DPO7000 Digital Phosphor Oscilloscopes, which feature advanced triggering, high waveform capture rate, and search capabilities and protocol decode needed for debugging. The series can also characterize and analyze 1st generation serial data. It is the latest generation of real-time digital phosphor oscilloscopes and the best solution to industry’s challenging signal […]

Filed Under: Digital Oscilloscope, digital phosphor oscilloscope, Oscilloscopes Tagged With: digital oscilloscope, digital phosphor oscilloscope, oscilloscope, Tektronix

Tektronix introduces TDS3000C Digital Phosphor Oscilloscope Series

January 25, 2011 By Test and Measurement Editor Leave a Comment

Tektronix-TDS3000C-Digital-Phosphor-Oscilloscope-Series

Tektronix (www.tek.com) has released its TDS3000C Digital Phosphor Oscilloscope Series, which features up to 5 GS/s sample rate and 500 MHz bandwidth, enabling users to view fast-changing signals fitted in a compact, battery-capable design. It is easy to use and has 25 automatic measurements and front-panel controls, minimizing the time spent on re-learning how to […]

Filed Under: Digital Oscilloscope, digital phosphor oscilloscope, Oscilloscopes Tagged With: digital oscilloscope, digital phosphor oscilloscope, oscilloscope, oscilloscopes, Tektronix
